NANO F / NANO60
COMBO KIT
[TL-LD830-F_TL-LD830]
[NANO F]
The USB-C rechargeable Nano F packs serious power into an ultra-compact form. Delivering up to 100 lumens through a precision-engineered OptiCube™ lens, it ensures you're seen on the road—even in broad daylight. Weighing just 27 grams, the Nano F is barely noticeable on your bars, yet it delivers high-impact visibility with six versatile light modes, including three Daytime HyperFlash™ options designed to pierce through traffic and urban glare.
- Compact and lightweight body
- 1 LED (100 lm)
- Highly visible during daytime
- OptiCube™ lens technology
- Lithium-ion Polymer rechargeable battery
- USB-C rechargeable (USB-C cable not included)
- Low battery indicator
- Six light modes including three Daytime modes (Daytime HyperFlash 1 / Daytime HyperFlash 2 / Daytime HyperFlash 3 / High / Low / Flashing)
- Mode memory function
- New rubber strap bracket which fits 22-35mm handlebars
- Snap System™ allows light to be positioned either vertically or horizontally into mount.
[NANO60]
The compact Nano60 is equipped with our latest OptiCube™ lens technology, providing daytime visibility. Small enough to forget it's on your bike, but always there when you need it. The included SP-14-RA bracket is compatible with modern aero seatposts. Snap System™ compatibility allows the light to be attached to a wide variety of mounts, including our saddle rail and rear rack brackets.
- Compact and lightweight body
- 1 LED (60 lm)
- Long rear beam projection
- Highly visible during daytime
- OptiCube™ lens technology
- Lithium-ion Polymer rechargeable battery
- USB-C rechargeable (USB-C cable not included)
- Low battery indicator
- Six light modes (High / Low / Flashing / Group Ride / Daytime HyperFlash 1 / Daytime HyperFlash 2)
- Mode memory function
- Battery Auto Save (The mode automatically changes to flashing when the battery power gets low.)
- New seat post bracket SP-14-RA which fits aero seat posts up to 130mm outer circumference
- Snap System™
※Design and specifications are subject to change without notice.
Tech Specs
- Dimension:
- [NANO F] 30 x 32 x 30 mm (without Rubber band)
[NANO60] 30 x 32 x 30 mm
- Weight:
- [NANO F] 27g
[NANO60] 20.5g
- Light source:
- [NANO F] White LED x1
[NANO60] Red LED x1
- Run time:
- [NANO F]
Daytime HyperFlash 1 (100 lumens):19hrs
Daytime HyperFlash 2 (80 lumens):11hrs
Daytime HyperFlash 3 (20 lumens):35hrs
High (100 lumens):1.25hrs
Low (5 lumens):23hrs
Flashing (10 lumens):65hrs
[NANO60]
High (20 lumens):3.5hrs
Low (3 lumens):20hrs
Flashing (6 lumens):60hrs
Group Ride (10 lumens):25hrs
Daytime HyperFlash 1 (60 lumens):15hrs
Daytime HyperFlash 2 (20 lumens):20hrs
- Battery:
- Li-ion Polymer rechargeable battery (3.7V-320mAH)
- Recharge time:
- 3hrs (0.5A)
- Mount size:
- [NANO F] φ22-35mm
[NANO60] φ21.5-32mm. Fits up to 130mm outer circumference. (SP-14-RA)
- Recharge/discharge number of times:
- about 300 times(until the rated capacity drops to 70%)
- Water resistant:
- IPX4
- Other:
- Battery auto save (NANO60), Low battery indicator, Light mode memory
